Complied with or exceeds Standard
▪ 2011/65/EU(ROHS2.0)
Features
▪ Light weight, durable, resistance to acid, aging resistant, corrosion resistant
▪ High tensile strength and bending properties, which make it to go through narrow pipes easily.
▪ Good temperature adaptability, the product will not soften in hot weather/nor become brittle in cold weather. It is usability will not be affected by temperature.
▪ Outer protect layer are made of high density polyethylene engineering plastic, which has good anti-UV capability.
▪ It surface has the advantage of smooth, wear-resistant and long service life.
▪ There are meter mark on the protect layer of duct rod.
▪ The length is 100m to 400m.
▪ There are kinds of colors for the rod to choose.
Technical Parameter
1. Reinforce Fiber glass
| Property | Data and Value | Property | data |
| Reinforcement | E-Glass Fiber | Min pulling strength | 4000N ± 5% |
| Glass content of inner part | 80-85% | Tensile modulus | >30000 MPa |
| Material of pulling rod | Epoxy fiber glass(inner) and
high density polyethylene(outer) | Consistency of rod | 150g ± 5% |
| Density | >150g/m | Flexural modulus | >30000 MPa |
| Diameter tolerance | ±0.10mm | Elongation at Break | 2.5-3% |
| Working temperature | -40 ~ +80℃ | | |
2. Polyethylene cover
Material: Medium Density polyethylene resin for the insulating and jacketing of telecommunication cables.
| Property | Data |
| Tensile strength | >150N |
| Environmental stress & crack resistance | >1000 hr |
| Heat stability | ok |
| Carbon Black | ok |
Ordering Information
Using the available configurations amend/create product codes using the formula below.
Part Number： CDR-ABC
Ordering Guide
| A | Rod Dia. | 3.2mm, 4.8mm, 6.4mm, 8.0mm , 9.5mm, 11.2mm, 12.7mm. |
| B | Fiber glass length | 100m to 400m |
| C | color | standard colour is Green (other colors may be available upon request). |
