Complied with or exceeds Standard
. GR-326-CORE
. TIA/EIA-568-C.3
. ANSI/TIA/EIA-455B
. IPC-8497-1
. UL-V0 flammability rating
. RoHS Compliant Directive 2002/95/EC
Features
. Compact Module type design
. Low back reflection
. Short wavelength devices
. Custom assemblies available
. Compatible with Fast Ethernet, Fiber Channel, ATM and Gigabit Ethernet
Ordering Information
Using the available configurations amend/create product codes using the formula below.
Part Number： LPC-AA-BCD
Ordering Guide
| AA | BB | C | D |
| Connector Type | Fiber Type | Loopback Module Type | Shield Body Color |
| FP,SP,SA,LP | OM1=62.5/125 OM1, OM2=50/125 OM2
OM3=50/125 OM3, OM4=50/125 OM4
G652D=9/125 G652D, G657A=9/125 G657A | L=Long type
S=Short type | NT=Natural
BK=Black |
Connector Type Code
| Code | Connector | Code | Connector | Code | Connector | Code | Connector | Code | Connector | Code | Connector |
| FP | FC/PC | FA | FC/APC | LP | LC/PC | LA | LC/APC | MU | MU | DN | DIN |
| SP | SC/PC | SA | SC/APC | TP | ST/PC | TA | ST/APC | MT | MTRJ | E2 | E2000 |
Ordering Sample
| Part Number | Description |
| LPC-LA-G652DSNT | LC/APC Fiber Optic Loopback Patch Cord, Singlemode G652D, Short Module type, Natura Color. |
